Tempo T2803 Dual LED Optical Test Source

INCLUDES:
• (1) SC Connector Adaptor (OPT046) 1 per Port
• (1) Operation Manual
• (1) QA Certificate
• (1) Set ILAC/ NATA Traceable Calibration Certificates
• (1) Carry Pouch
• (1) Carry Strap
• (1) 50 & 62.5 µm Fiber Mandrel Wrap Set for Multimode Sources (OPT701)
• (1) USB-A to USB-Micro Type Cable

FEATURES:
• Encircled Flux compliant
• Easy to use, rugged & versatile
• Long battery life, micro USB power/charger
• Interchangeable connectors with dust cap & tilt bail
• Superior re-connection repeatability, < 0.1 Db
• Excellent stability
• Autotest & Multi-Fiber ID Tone generator
• Full QA & test reports ISO/IEC 17025 traceable

SPECIFICATIONS:
• Output Wavelength: Port 2: 850, 1300 nm LED
• Output Power: -20 dBm ±1 dB (@ 62.5/125 µm)
• Adjust Output Power: Adjustable over 7 dB in 0.01 dB steps
• Short Term Stability (for 15 min, Typical ±2 °C, After Warm Up, ORL < -25 dB): 0.01 dB
• Stability Over Temperature: 0.35 dB (Typical)
• Wavelength Drift: 0.4 nm /°C (Typical)
• Mode Controlled Source: 50/125µm Compliant: IEC 61280-4-1 {Ed.1.0}, TIA 526-14A & TIA TSB-178
• Reconnection Repeatability (95% Confidence): 0.05 dB
• Calibration Validity (ISO/IEC 17025): 3 Years
• Modulated Output: 270 Hz, 1 kHz, 2 kHz ± 2 %, 12 Multi-Fiber ID Tones
• Autotest (Not Available for 470, 540 nm LED Sources): Compatible with KI Autotest Power Meter Port & Matching ?
• Power: Battery / External Power Via USB
• Battery Types: 2x AA (LR6) Alkaline / 2x AA NiMH AA (Rechargeable Via USB)
• Battery Life: Laser/LED Source: 90/80 hours in Autotest, Typical


This dual LED source is a general purpose test source for multimode systems at 850 / 1300 nm. Typical applications include fiber optic attenuation measurement, polarity testing and fiber identification on critical systems.
